Planetory Mixer

Machine Description:

Planetory Mixer is a modern heavy duty mixer designed specially for uniform Mixing by planetary movement of beater(agitator). Detachable cylindrical bowl with flat / hemispherical bottom of suitable dimension and Batter / Dough Hook / Wire Whip Cage Type blade is constructed out of SS-316 / SS-304 / MS Material. Detachable agitator is bolted / fitted manually by simple twisting action.

Drive:

The Blade is driven by Single / Two / Variable Speed electric motor with suitable gearbox. Planetary disc is rotated clockwise and blade in an anti-clockwise direction on its own axis with suitable rpm. If variable speed is required, AC frequency unit will also be provided.

Stand:

The whole drive assembly is rested on MS column with heavy base frame and mixing bowl is fixed with MS fabricated bracket. The bowl with bracket is raised/down manually by handle in respect of small machines and motorized or hydraulic system is provided for lifting / lowering drive head with agitator in respect of heavy duty machines.

Special Features:

  • Bowl will be jacketed for heating or cooling.
  • Mixer can be designed to operate under vacuum to avoid air entrapment in product during mixing.
  • The bowl will be provided with caster wheels for easy movements for cleaning, washing and handling mixed materials.
  • Single blade / double blades and a Teflon edged scraper will be provided for scrapping the material from the sidewall.
  • GMP / NON-GMP / FLP construction

Applications:

Generally used in mixing of liquid-liquid, liquid-solid, solid-solid blending like wet mass, ointments, creams, toothpastes, lotions, cosmetics, pesticides & insecticide formulations, adhesives, colors and pigments, food & confectionaries, ceramics, rubber compounds, resins etc.
